EL Series Micro Type AC Drive

Get a Price/Quote

MOQ : 1 Piece

EL Series Micro Type AC Drive Specification

Processor Type
Digital Signal Processor (DSP)

Screen Size
4 Digit LED Display

Remote Control
Yes

Features
Overload Protection, Compact Design, Easy Programming

Drive Type
Micro Type AC Drive

Control Type
Vector Control, V/F Control

Application
General Machinery, Textile, HVAC, Conveyor, Pumps, Fans

Frequency
50/60 Hz

Automation Grade
Automatic

Speed Range
1:100

Connectivity Type
RS485 (Modbus-RTU)

Load Capacity
Heavy & Normal Duty

Weight
1.2 kg

Phase
Single Phase / Three Phase

Mounting Type
Panel Mount

Cable Length
Customizable

Sensor Type
No Sensor Required

IP Rating
IP20

Material
ABS Engineering Plastic

Power
0.4kW to 2.2kW

Temperature
-10C to +40C

Voltage
220V / 380V

Protection Class
IP20

Start/Stop Control
Keypad / Terminal / PLC

Multiple Protection
Over-voltage, Over-current, Overheat

Input Frequency
47-63Hz

EMC Compliance
C3

Analog Input
0-10V, 4-20mA

Cooling Method
Built-in Cooling Fan

Output Frequency Range
0-400 Hz

Noise Level
60dB

Humidity
<95% RH (non-condensing)

Braking Unit
Built-in

Dimensions
150 x 90 x 100 mm (approx)

Display
LED Digital

Overload Capability
150% for 60 seconds

Digital Input
3

EL Series Micro Type AC Drive Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Pieces Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

About EL Series Micro Type AC Drive

Discover the EL Series Micro Type AC Drive, a Special Reserve for those seeking towering performance in industrial automation. Renowned for its glorious control, this sought-after drive offers unsurpassed Savings and reliability for applications ranging from HVAC systems to textile machinery. With a built-in cooling fan, advanced digital signal processor, robust overload protection, and C3 EMC compliance, it assures dependable operation. Its IP20 design, compact ABS enclosure, and easy keypad/PLC control elevate both installation flexibility and safety. Perfect for dynamic and heavy-duty environments, ensuring lasting value.

Versatile Application Breadth

The EL Series Micro Type AC Drive finds its stride across a wide array of applications including textile production, general machinery, HVAC, conveyors, industrial pumps, and powerful fans. Engineered for mediums where precision and stability are paramount, this drive excels in automation and speed control. Its innovative design is ideally used for enhancing productivity in both general and specialist environments, making it the go-to solution for industries that rely on consistent and reliable motor control.

Packaging Logistics & Easy Purchasing

Packaging for the EL Series Micro Type AC Drive ensures safety and integrity during transit, with robust materials safeguarding each unit. Logistics flexibility is prioritized, providing swift delivery options tailored to your outlay. Payment terms are competitive, promoting a transparent quotation process for every purchase. Sample policies support evaluation prior to order commitments, enabling customers to experience the product firsthand and make informed decisions with confidence.

FAQ's of EL Series Micro Type AC Drive:

Q: How does the built-in cooling fan benefit the EL Series Micro Type AC Drive?

A: The built-in cooling fan ensures that the drive maintains optimal temperature levels during operation, enhancing reliability, prolonging product life, and maintaining consistent performance even under heavy-duty cycles.

Q: What is the process for programming and controlling the drive?

A: Programming the EL Series Micro Type AC Drive is straightforward, thanks to its easy keypad interface. Control options include terminal and PLC connections, offering flexible integration into various automation setups.

Q: Where can the drive be used for optimal results?

A: The drive is optimally used in general machinery, textile operations, HVAC systems, conveyors, pumps, and fans. Its robust design supports both industrial and commercial environments requiring variable frequency control.

Q: What makes this drive suitable for both heavy and normal duty?

A: With a load capacity supporting both heavy and normal duty cycles and a powerful overload capability of 150% for 60 seconds, the drive handles demanding applications without compromising safety or performance.

Q: When should the built-in braking unit be utilized?

A: The built-in braking unit comes into play during rapid deceleration or emergency stops, helping to maintain safe operational standards and reducing wear on connected machinery.
